Holding two metal pieces at a clean angle can slow down a welding project, especially when you need both hands free for tacking, soldering, or setup. The ABN Arrow Welding Magnet Set is made to solve that problem with six magnetic angle holders in three strength levels. This review helps you decide whether the ABN 2400 set gives you enough holding support, angle flexibility, and workshop value for your metalworking projects. It is a useful helper for ferrous metal work, but it is not a replacement for proper clamps, welding safety gear, or careful fit-up.
Quick Verdict
Rating: 8/10, Recommended with caveats
Best For: DIY welders, auto body workers, hobby fabricators, and shop users who need quick 45, 90, and 135-degree magnetic positioning.
Bottom Line: The ABN Arrow Welding Magnet Set gives you six angle holders with 25 lb, 50 lb, and 75 lb capacity options, which makes it more flexible than a single-size magnet. The main tradeoff is compatibility, since these magnets only work on ferrous metals and should not sit too close to the weld area.
Key Takeaways
- The ABN Arrow Welding Magnet Set includes six magnetic angle holders for welding, soldering, assembling, and installing metal parts.
- The arrow design supports 45, 90, and 135-degree positioning for common corner, square, and angled layouts.
- The package includes two 25 lb magnets, two 50 lb magnets, and two 75 lb magnets for different project sizes.
- The magnets are built from high-quality steel with a powder-coated finish for workshop durability.
- They work on ferrous metals, so they are not suitable for aluminum, copper, brass, or other non-magnetic materials.
- You should keep them away from children and avoid welding too close to the magnets because of the strong magnetic force and heat exposure.
| Specification | Detail |
|---|---|
| Brand | ABN |
| Model | ABN 2400 |
| Product type | Arrow welding magnet set / positioning welding clamps |
| Package quantity | 6 individual welding magnets |
| Angle options | 45, 90, and 135 degrees |
| Holding capacities | 2 magnets up to 25 lb, 2 magnets up to 50 lb, and 2 magnets up to 75 lb |
| Material | High-quality steel |
| Finish | Powder-coated finish |
| Compatibility | Ferrous metals only |
| Common uses | Welding, soldering, assembling, and installing metal objects |
| Warranty | One-year manufacturer warranty against defects in materials and workmanship |
| Safety note | Keep away from children and do not weld too close to the magnets |
What Is the ABN Arrow Welding Magnet Set?
The ABN Arrow Welding Magnet Set, model ABN 2400, is a 6-piece set of magnetic welding holders. Each magnet uses an arrow-style shape that lets you position metal at 45, 90, or 135 degrees before welding, soldering, assembling, or installing parts.
The set gives you three holding-strength sizes instead of six identical magnets. You get two magnets rated up to 25 pounds, two rated up to 50 pounds, and two rated up to 75 pounds, so you can choose the right holder for light panels or heavier ferrous metal pieces.
These magnets are best used as setup and positioning aids. They help hold parts in place while you check alignment and make tack welds, but you should still confirm the joint, use safe welding practices, and add stronger clamps when the workpiece needs extra mechanical control.
Before You Buy: These magnets work only with ferrous metals. They will not properly hold aluminum, copper, brass, stainless grades with weak magnetic response, or painted surfaces where the magnet cannot grip well.
Who Should Buy It?
Best For
- DIY welders who need hands-free help during tack welding and layout.
- Auto body and metalworking users who often position panels at 45, 90, or 135 degrees.
- Shop owners who want multiple magnet sizes for light, medium, and heavier ferrous metal projects.
Skip If
- You mainly work with aluminum, copper, brass, or other non-ferrous materials.
- You need an adjustable clamp with mechanical pressure instead of magnetic holding force.
- You work on very precise fixtures where magnets could pull small parts out of position.
Key Features of the ABN Arrow Welding Magnet Set
Three Common Angle Options
The main strength of this set is the arrow-shaped layout. Each magnet can help you create 45, 90, and 135-degree positions, which covers many common metalworking tasks such as square corners, angled supports, brackets, frames, and panel placement.
This design is useful when you need a quick reference angle before making a tack weld. It can reduce the time you spend holding two pieces by hand, but you should still verify the final alignment with a square or measuring tool before welding the joint fully.
Six Magnets With Three Strength Levels
The package includes two 25 lb magnets, two 50 lb magnets, and two 75 lb magnets. That mix gives you more flexibility than a single-size set because you can use smaller magnets for lighter parts and the larger 75 lb magnets for heavier ferrous pieces.
Holding capacity depends on clean contact, flat surfaces, metal thickness, and how the load pulls against the magnet. Treat the rating as a positioning aid, not as a lifting or safety rating for suspended workpieces.
Hands-Free Positioning
The ABN magnets support two metal panels at a needed angle so your hands stay free for setup, tack welding, or soldering. This can be especially helpful when you work alone or need to make repeated angle setups across several pieces.
The benefit is speed and convenience. The limitation is that magnetic force does not replace careful clamping when vibration, heavy weight, gaps, or heat movement can shift the workpiece.
Build Quality and Materials
ABN lists the magnets as high-quality steel with a powder-coated finish. That construction suits normal workshop handling and helps protect the body of the magnet during metalworking tasks.
The powder-coated finish adds durability, but you should still keep the magnets clean. Metal shavings, slag, dust, and oil can reduce contact and make the magnet less secure on the work surface.
Pro Tip: Before each setup, wipe the magnet face and the workpiece surface. A clean, flat contact point gives the magnet better grip and helps you spot alignment problems before you tack weld.
Performance and Usability
The ABN Arrow Welding Magnet Set performs best as a quick positioning tool for ferrous metal. You can place one or more magnets along a joint, check the angle, and use your free hands to set up the weld or soldering task.
The three angle options make the set practical for shop work where you do not want to build a separate jig for every small project. The 25 lb, 50 lb, and 75 lb capacities also let you match the magnet to the size and weight of the part.
For best results, use these magnets during layout and tack welding. Once the joint is secure, move the magnets away from direct heat when possible, then finish the weld with the workpiece properly supported.
How It Performs in Real Use
For Basic Frame and Corner Work
For square corners and simple frames, the 90-degree position is the most useful angle. You can set two ferrous pieces against the magnet, check the corner, and make a tack weld without fighting the parts by hand.
For Angled Brackets and Supports
The 45 and 135-degree positions help when you work on angled supports, braces, and decorative metal layouts. These angles make the set more useful than a basic square-only welding magnet.
For Auto Body and Panel Positioning
The smaller 25 lb and 50 lb magnets can help with lighter panels and positioning tasks. They are useful when you need temporary support, but you should avoid relying on magnets alone when a panel is under tension or does not sit flat.
For Heavier Shop Projects
The 75 lb magnets provide the strongest holding option in the set. They can help support heavier ferrous parts during layout, but you should still add clamps or supports for heavy pieces that could fall, twist, or shift during welding.
Setup Tips Before First Use
- Test the metal first: Touch the magnet to the workpiece before setup. If the pull feels weak, the material may not be a good match.
- Clean both surfaces: Remove loose debris, heavy dust, oil, and metal shavings from the magnet and workpiece.
- Use the right size magnet: Use 25 lb magnets for light positioning, 50 lb magnets for medium work, and 75 lb magnets for heavier ferrous pieces.
- Check the angle before welding: Use a square, angle finder, or measuring tool to confirm alignment before you tack the joint.
- Move magnets away from heat: Do not weld too close to the magnets, and keep them away from direct heat when possible.
- Store them carefully: Keep the magnets away from children, electronics, cards with magnetic strips, and loose metal debris.
Compatibility and Safety
The ABN Arrow Welding Magnet Set is made for ferrous metals. That means it works best with magnetic steel and similar materials. It is not the right tool for aluminum, copper, brass, or other non-magnetic materials.
The strong magnetic force is helpful during setup, but it also creates pinch and handling risks. Keep the magnets away from children, and do not place fingers between the magnet and a metal surface when the magnet snaps into position.
ABN also warns not to weld too closely to the magnets. Heat, spatter, and magnetic interference can create problems, so use the magnets as layout aids and move them away from the hottest part of the work whenever practical.
The manufacturer also lists a California Proposition 65 warning for this product. Review the product label and seller information before use, especially if you need to follow specific workplace, shop, or state safety requirements.
Pros and Cons
Pros
- Six-piece set gives you more coverage than a single welding magnet.
- 45, 90, and 135-degree positions cover common workshop angles.
- Includes 25 lb, 50 lb, and 75 lb magnet pairs for different project sizes.
- Hands-free support helps with tack welding, soldering, and metal assembly.
- Steel body and powder-coated finish suit regular workshop use.
Cons
- Only works on ferrous metals, so it is not useful for most aluminum or copper projects.
- Magnetic holding force depends on surface contact, cleanliness, and metal thickness.
- Not a substitute for mechanical clamps when the workpiece is heavy, stressed, or unsafe to leave unsupported.
Is It Worth the Price?
The ABN Arrow Welding Magnet Set is worth considering if you want several magnetic positioning holders in one package. Because it includes six magnets across three holding capacities, it offers strong value for the price compared with buying one or two separate magnets.
You get the most value if you work on frequent small and medium ferrous metal projects. The set is especially useful when you need repeatable angle positioning for tack welding, brackets, frames, panel alignment, or general shop assembly.
It is not the best fit if you need precision fixturing, non-ferrous metal support, or a clamp that applies mechanical pressure. In those cases, you may need welding clamps, corner clamps, jigs, or a more specialized fixture system.
How It Compares to Alternatives
Compared with a single 90-degree welding magnet, the ABN set gives you more flexibility because each arrow magnet supports 45, 90, and 135-degree positioning. The six-piece package also lets you place multiple holders along a frame or use different strength levels on different parts of the same job.
Compared with adjustable welding clamps or dedicated corner clamps, these magnets are faster to place but less secure under load. The ABN set makes the most sense if you want quick magnetic setup help, while mechanical clamps are better when pressure, repeatable precision, or non-magnetic material support matters more.
Frequently Asked Questions
Can the ABN Arrow Welding Magnets hold aluminum?
No. These magnets are designed for ferrous metals, so they will not properly hold aluminum, copper, brass, or other non-magnetic materials. Test your workpiece before setup if you are unsure.
How many magnets come in the set?
The ABN 2400 set includes six individual welding magnets. The package includes two 25 lb magnets, two 50 lb magnets, and two 75 lb magnets.
What angles can these welding magnets hold?
The arrow design supports 45, 90, and 135-degree angles. These are common positions for frames, brackets, corners, supports, and many general metalworking layouts.
Can beginners safely use these welding magnets?
Yes, beginners can use them as long as they follow basic welding safety practices. Wear proper protective gear, keep fingers away from pinch points, and do not weld too close to the magnets.
Do these magnets replace welding clamps?
No. They are positioning aids, not full replacements for mechanical clamps. Use clamps or supports when the workpiece is heavy, under stress, or unsafe to hold with magnet force alone.
How should you clean the magnets after use?
Wipe them with a dry or slightly damp cloth after use. Remove metal shavings, dust, and oil from the magnet faces so they can make better contact on the next project.
What is the warranty on the ABN 2400 magnet set?
ABN lists a one-year manufacturer warranty against defects in materials and workmanship from the original retail purchase date. Check the current seller terms before buying because warranty handling can vary by retailer.
Who should skip this magnet set?
Skip it if you mostly work with non-ferrous metals or need a clamp that applies pressure. You should also choose a different fixture if your work requires exact repeatable positioning under load.
The Bottom Line
The ABN Arrow Welding Magnet Set is a smart buy if you work with ferrous metal and want quick hands-free help for 45, 90, and 135-degree positioning. Its best strength is the six-piece mix of 25 lb, 50 lb, and 75 lb magnets, while its main limitation is that it cannot handle non-magnetic metals or replace proper clamps in demanding setups.
Buy it if you want a practical positioning aid for welding, soldering, assembling, or installing metal parts. Skip it if your work needs precision fixturing, mechanical pressure, or support for aluminum and other non-ferrous materials.
