ANDELI 135A MIG Welder Review

Choosing a small welder is mostly about matching its real output, processes, and accessories to the work you plan to do. The ANDELI MIG-135PLUS 135A MIG Welder combines pulse flux-core MIG, standard gasless MIG, Lift TIG, and MMA functions in a 110V/220V portable machine. Its low weight, synergic controls, and full-kit listing make it appealing for beginners and home repairs, but the Lift TIG torch is sold separately and this is not a gas-MIG or spool-gun aluminum setup. This review helps you decide whether its strengths fit your garage, maintenance, or light fabrication projects.

Key Takeaways

• The machine supports pulse flux-core MIG, standard gasless MIG, Lift TIG, and MMA welding.
• Dual-voltage 110V/220V input gives you more location flexibility, but available output still depends on the circuit and setup.
• It supports .030, .035, and .040 inch flux-core wire and is listed for mild steel up to 5.0 mm thick.
• The 4.1-inch display, synergic control, adjustable inductance, and 2T/4T modes help simplify setup.
• The Lift TIG torch is sold separately, and this model is not the right choice for buyers who need confirmed aluminum MIG capability.

Key Specifications

What Is the ANDELI MIG-135PLUS?

The ANDELI MIG-135PLUS is a compact inverter welder built around self-shielded flux-core wire. It gives you pulse flux-core MIG and standard gasless MIG modes for wire welding, plus MMA for stick electrodes and Lift TIG capability when you add the correct torch.

ANDELI markets the machine as both a three-in-one and four-in-one welder. The difference is mainly how the seller counts pulse flux-core MIG and standard gasless MIG. In practical terms, you get two flux-core control modes plus Lift TIG and stick welding, not a conventional gas-MIG setup with a shielding-gas system.

The main selling point is portability. At 9.04 lbs, it is easier to carry between a garage, driveway, shed, or maintenance area than a large transformer machine. The 110V/220V input also lets you use common household power for lighter jobs and a suitable 220V circuit when you need more available output.

Who Should Buy It?

Feature-by-Feature Review

Pulse Flux-Core and Multi-Process Modes

The MIG-135PLUS combines pulse flux-core MIG, standard gasless MIG, Lift TIG, and MMA. Pulse control can help smooth the arc and reduce harsh transitions when the wire, voltage, and material are matched correctly. Standard gasless MIG remains the simplest mode for common repair work because the flux inside the wire provides shielding without a gas bottle.

MMA adds useful flexibility for outdoor repairs, thicker joints, or surfaces where stick welding is more practical. Lift TIG can produce cleaner, more controlled beads on suitable steel, but it requires a separate torch and more operator skill. You should treat Lift TIG as an expansion option, not a complete out-of-box TIG package.

Synergic Controls and Inductance Adjustment

Synergic control links recommended settings to your selected wire and current range, which reduces the number of adjustments you need to make when starting. You can still fine-tune the output manually as your joint, travel speed, and preferred arc feel change.

Adjustable inductance changes how soft or crisp the arc feels. A softer setting can help calm spatter, while a crisper arc may improve response on some joints. The control is useful, but it does not replace correct wire tension, clean contact tips, sound grounding, and practice on scrap material.

110V and 220V Performance

Dual-voltage input is one of the strongest practical reasons to choose this machine. A 110V outlet is convenient for thin material, short welds, and portable repair work. A correctly installed 220V circuit gives the welder more electrical headroom for higher settings and thicker material.

The 5.0 mm mild-steel claim is a maximum listing figure, not a guarantee for every joint. Actual penetration depends on input voltage, joint preparation, fit-up, wire diameter, travel speed, and whether you can make multiple passes. For structural or safety-critical welds, use an appropriately rated machine and qualified procedure.

Wire Support and Feeding

The machine supports .030, .035, and .040 inch flux-core wire. Smaller wire can be easier to control on thinner material, while larger wire may suit higher-output work when the machine, joint, and wire type support it. Always follow the wire manufacturer’s polarity and parameter guidance.

The integrated wire feed system and 2T/4T trigger modes improve usability. In 2T mode, you hold the trigger while welding. In 4T mode, the machine can reduce hand fatigue during longer beads because the trigger sequence controls start and stop without constant pressure.

Display, Controls, and Portability

The 4.1-inch LED display gives you a clear view of current settings. Its transparent cover helps protect the panel from sparks, dust, and small impacts, which is useful in a garage where the machine may sit close to grinding and fabrication work.

At 9.04 lbs, the MIG-135PLUS is light enough to move with one hand using the top handle. The listed dimensions, about 12.99 × 5.91 × 9.37 inches, also make it easier to store on a shelf or cart. You still need room for the torch, ground cable, electrode holder, wire spool, helmet, gloves, and dry consumable storage.

Included Kit and Accessory Limits

The Amazon listing describes a full kit with the welder, gasless wire, electrode holder, MIG torch, auto-darkening helmet, and leather gloves. This gives a first-time buyer more of the basic equipment needed to start practicing flux-core or stick welding.

Package contents can change by color, seller, or bundle, so compare the product title and included-items images before checkout. The listing also states that the Lift TIG torch is sold separately. Consumables such as contact tips, nozzles, wire, electrodes, and helmet lenses will need replacement over time.

How It Performs in Real Use

For Beginner Practice

Synergic control, a large display, and gasless wire reduce setup complexity for a new welder. You still need to learn travel angle, stick-out, sound, puddle control, and metal preparation. Start on clean scrap of the same thickness as your project before welding the final part.

For Garage and Home Repairs

The machine is well matched to brackets, lawn-equipment repairs, carts, shelves, small frames, and similar mild-steel work within its capacity. Flux-core wire works outdoors better than gas MIG in light wind, but you should still shield the work area from strong airflow and remove slag between passes.

For Portable Maintenance

The low weight makes it practical for jobs away from a fixed welding table. The limiting factor is often power, not machine weight. Confirm the outlet, breaker, extension-cord rating, and grounding path before moving the welder to a driveway, shed, or remote work area.

For Stick and Lift TIG Use

MMA mode gives you a useful backup process when wire welding is not ideal. Lift TIG expands the machine’s range for controlled steel work, but the separate torch and added setup cost matter. Buyers who expect frequent TIG work may be better served by a machine designed around TIG from the start.

Setup Tips Before First Use

1. Verify the circuit: Match the plug, adapter, breaker, and supply voltage to the manual. Do not assume every 110V outlet can deliver the same usable output.
2. Check wire polarity: Use the polarity specified for your exact flux-core wire. Incorrect polarity can cause excessive spatter and poor penetration.
3. Set drive-roll tension carefully: Use enough pressure to feed wire without crushing or deforming it.
4. Clean the work and ground point: Remove paint, scale, rust, oil, and coatings where practical. Attach the ground clamp to clean metal close to the joint.
5. Test on scrap: Start with the synergic recommendation, then adjust voltage, wire speed, and inductance in small steps.
6. Confirm the bundle: Inspect the torch, contact tip, wire, helmet, gloves, adapter, and electrode holder before the return window closes.

Safety and Electrical Notes

The listed protection system includes automatic voltage compensation plus over-current, overload, overheating, and over-voltage safeguards. These features protect the machine, but they do not protect you from arc radiation, fumes, hot metal, fire, electric shock, or compressed-gas hazards.

Wear an appropriate welding helmet, flame-resistant clothing, leather gloves, and closed footwear. Provide effective ventilation, remove flammable materials, and keep a suitable fire extinguisher nearby. Never weld on sealed containers, unknown coated metal, or parts that may hold fuel or hazardous residue.

Use extension cords only when the manual permits them and size the cord for the circuit, voltage, length, and current draw. Stop if the plug, adapter, outlet, or cord becomes hot. For new 220V circuits or uncertain wiring, use a qualified electrician.

Pros and Cons

Is It Worth the Price?

The MIG-135PLUS fits the budget-to-mid-range part of the portable welder market. Its value comes from combining dual voltage, pulse flux-core capability, stick welding, optional Lift TIG, a large display, and a listed starter kit in one compact package.

It offers the best value to a beginner or DIY user who expects flux-core welding to be the main process and wants stick capability for added flexibility. It is less compelling if you already own a helmet and accessories, need a dedicated TIG package, or plan to weld aluminum with gas MIG.

Because seller bundles and warranty terms can change, compare the current package contents rather than judging the deal by the machine alone. A lower price is not a better value if the bundle omits the adapter, protective gear, or accessories you need.

How It Compares to Alternatives

The YESWELDER FLUX-135 and TOOLIOM TL-135M are worth comparing if you want another compact synergic flux-core machine. Forney’s Easy Weld 140 FC-i is simpler and backed by a well-known welding brand, but it is focused on 120V flux-core work rather than the ANDELI’s dual-voltage, multi-process approach.

The ANDELI makes the most sense when portability, 110V/220V flexibility, pulse flux-core controls, and an accessory bundle matter more than having a dedicated gas-MIG or TIG platform.

Frequently Asked Questions

The Bottom Line

The ANDELI MIG-135PLUS is a strong fit for beginners and DIY users who want a light, dual-voltage flux-core welder with stick capability and optional Lift TIG. Its main strengths are process flexibility, simple controls, and portability, while its main limits are the separate TIG torch, uncertain seller-specific bundle details, and lack of confirmed aluminum MIG support.

Choose it for home repairs, garage projects, and occasional portable work. Skip it if you need gas MIG, frequent aluminum welding, a complete TIG package, or production-grade output.
